Model | B400-6-P | Max capacity | 400kg |
Overall Dimension | 2160X960mmX920mm | Power supply | 4.5-5.5 bar compressed air, Consumption of compressed air 75～94L/min |
Control mode | Manual hand slide valve control Vacuum suction and release | Suction and release time | All less than 5 seconds; (Only the first absorption time is slightly longer, about 5-10 seconds) |
Maximum pressure | 85%vacuum degree (about 0.85Kgf) | Alarm pressure | 60%vacuum degree (about 0.6Kgf) |
Safety factor | S>2.0; Horizontal handling | Dead weight of equipment | 110kg（approximate） |
Model | B400-6-P | Max capacity | 400kg |
Overall Dimension | 2160X960mmX920mm | Power supply | 4.5-5.5 bar compressed air, Consumption of compressed air 75～94L/min |
Control mode | Manual hand slide valve control Vacuum suction and release | Suction and release time | All less than 5 seconds; (Only the first absorption time is slightly longer, about 5-10 seconds) |
Maximum pressure | 85%vacuum degree (about0.85Kgf) | Alarm pressure | 60%vacuum degree (about0.6Kgf) |
Safety factor | S>2.0; Horizontal handling | Dead weight of equipment | 110kg（approximate） |
Model | B400-6-T | Max capacity | Horizontal handling 400kg |
Overall Dimension | 2160X960mmX910mm | Power input | AC220V |
Control mode | Manual push and pull rod control absorption | Suction and discharge time | All less than 5 seconds; (Only the first absorption time is slightly longer, about 5-10 seconds) |
Maximum pressure | 85%vacuum degree（about 0.85Kgf） | Alarm pressure | 60%vacuum degree （about 0.6Kgf） |
Safety factor | S>2.0;Horizontal absorption | Dead weight of equipment | 95kg（approximate） |
