AC/DC TIG 200 pulse welding machine with plasma ST with 200 A TIG MMA / plasma cutter
Output current (A) WELD CUT | 10-200 A 20-50 A |
Mains voltage (V) | 400 V AC (+- 15%) / 3 Ph |
Maximum mains current (I1max)WIG / MMA / CUT) | 31.3 A / 32.0 A / 34.4 A |
Maximum effective mains current (I1eff)(WIG / MMA / CUT) | 16.5 A / 14.3 A / 15.2 A |
Weight unit (kg) | 13 kg |
Dimensions L x W x H (mm) Unit | 455 x 220 x 370 |
Mains connection | SchuKo type CEE 7/7 |
Air pressure (Bar) | 3,5 - 4 bar |
Air flow (L/min) | min. 100 L/min |
